RFCN-302

Long range datalink SDR radio 2*1w

RadioForce series radios, based on SDR architecture

Can be loaded with different waveforms to meet the diverse needs from different users

RFCN-302 series support mesh mode, point-to-point and point-to- multipoint modes. IAS( Interference avoidance scheme) is supported

RFCN-302 is a compact datalink module which have military grade protection handheld radio, Rich interfaces are provided with this module. It is ideal for Man-Unmanned teaming

Communication performance

Waveform	cofdm
Working mode	Ad hoc network, point-to-point, point-to-multipoint
TX power	*30dBm 2 channels**
Frequency	U/L/S/C customizable
RX sensitivity	-108dBm@bandwidth=1.25MHz
Bandwidth	From 1.25MHz to 10MHz
Data Throughput	Max 10MHz： up to 30Mbps (Diversity) up to 60Mbps (MIMO) （License dependant）
Network capacity	up to 64 nodes in a single network
Anti-interference	interference avoidance scheme（optioned）
LPD/LPI	Supports silent mode

Interface	ETH，USB,COM,TALK,GPS
Power consumption	typical 8w
Sealing	IP67
Distance	LOS≥30km NLOS≥1km

Powersupply
Adapter	12V/60w
consumption	Typical8w

Physical
Dimension（mm）	*14012340*
weight（g）	902

Interface
RF	*TNC2**
USB	USB2.0，fischer 10pin
eth	RJ45, fischer 10pin
Talkback	fischer 7pin
DC IN	fischer 2pin

Configuration

	Name	Quantity	P/N	Descriton	remark
1	Radio	1	RFCN-302	Radio itself
2	Spring antenna	2	LPA-****TNC-2.5-S	2.5dB
3	GPS antenna	1	LPA-****SMA-GPS	GPS,BD,GNSS
4	Eth cable	2	LPCA-ETH-RJ45	Circular connector-RJ45 socket
5	Power adapter	1	LPCA-PWR-60w	24V, 2.5A
